DC COMPACT CURRENT SENSORS (ICD SERIES)
Compact, shunt-based current sensing for automotive applications, including UPS and energy storage systems, battery applications, and fuel cells. An affordable solution for 12-48V systems that don’t require galvanic isolation. Minimizes external temperature influences. Measures its own current consumption.
- Available in three current ranges—up to ±500 A
- 16-bit analog-digital converter
- Communication based on CANbus 2.0
- Up to 2500A overcurrent (OC) range
- Customer configurable parameters
- Output rate: 1 KHz
- Sleep mode
| Model | Nominal Sensing Range | OC range | Max Load (200ms) | CAN Termination | Supply Voltage | Product Details |
|---|---|---|---|---|---|---|
| ICD-A 100-CAN-1-12 | +/- 100 A | +/- 500A | +/- 2000 | yes | 12V | View More |
| ICD-A 300 CAN-2-12 | +/- 300A | +/- 1500A | +/- 3600 | no | 12V | View More |
| ICD-A 500-CAN-1-12 | +/- 500A | +/- 2500A | +/- 6000 | yes | 12V | View More |
| ICD-A-500-CAN-2-12 | +/- 500A | +/- 2500A | +/- 6000 | no | 12V | View More |
